SYS-R162-Z10 (rev. A00) - 1U - Server
- Order number: SYS-R162-Z10-A00
sysGen/GIGABYTE Server SYS-R162-Z10 (rev A00), Mainboard MZ12-HD2... more
Product information "SYS-R162-Z10 (rev. A00) - 1U - Server"
sysGen/GIGABYTE Server SYS-R162-Z10 (rev A00), Mainboard MZ12-HD2
Applications
- DB Processing
- Cloud Computing
- Data Center Appilcations
Features
- Compatible with 3 x NVIDIA Tesla® PCIe GPU cards
- Single AMD EPYC™ 7002/7003 series processor family
- 8-Channel RDIMM/LRDIMM DDR4, 8 x DIMMs
- 2 x 1Gb/s LAN ports (Intel® I350-AM2)
- 1 x Dedicated management port
- 10 x 2.5" U.2 hot-swappable SSD bays
- 6 x 2.5" NVMe/SATA/SAS hybrid ports
- 4 x 2.5" NVMe ports without SATA/SAS supported
NOTE: CPU TDP is limited to 155W if using M.2 device - 3 x PCIe x16 expansion slots
- 1 x OCP 2.0 Gen3 x16 mezzanine slots
- 3 x M.2 slot: M-key, PCIe Gen3 x4, Supports NGFF-2242/2260/2280/22110 cards
- Aspeed® AST2500 remote management controller
- 1200W (240V) 80 PLUS Platinum redundant PSU
| Applications: | Cloud Computing, Data Center |
| Case Depth: | 28.74 (730mm) |
| CPU Socket: | Single Socket |
| CPU Type: | AMD EPYC 7002 ROME (2.Gen), AMD EPYC 7003 MILAN (3.Gen) |
| DIMM Slots: | 8 DIMMs |
| Drive Bays Form Factor: | 2.5", M.2 |
| SSDs/HDDs: | 10 |
| Form Factor: | 1U |
| GPU Type: | PCIe |
| Max. GPU Count: | 3 GPUs |
| On-board Network: | 1GbE |
| Number of Nodes per System: | 1 Node |
| PCIe Slots: | 3 PCIe Slots |
| Redundant Power Supply: | Redundant Power Supply incl. |
| Remote Management: | Remote Management incl. |
| Storage Interface: | NVMe (native), SAS (native), SATA (native) |
| System Type: | Super Server |
Related links to "SYS-R162-Z10 (rev. A00) - 1U - Server"
Properties: "SYS-R162-Z10 (rev. A00) - 1U - Server"
| Applications: | Cloud Computing, Data Center |
| Case Depth: | 28.74 (730mm) |
| CPU Socket: | Single Socket |
| CPU Type: | AMD EPYC 7002 ROME (2.Gen), AMD EPYC 7003 MILAN (3.Gen) |
| DIMM Slots: | 8 DIMMs |
| Drive Bays Form Factor: | 2.5", M.2 |
| SSDs/HDDs: | 10 |
| Form Factor: | 1U |
| GPU Type: | PCIe |
| Max. GPU Count: | 3 GPUs |
| On-board Network: | 1GbE |
| Number of Nodes per System: | 1 Node |
| PCIe Slots: | 3 PCIe Slots |
| Redundant Power Supply: | Redundant Power Supply incl. |
| Remote Management: | Remote Management incl. |
| Storage Interface: | NVMe (native), SAS (native), SATA (native) |
| System Type: | Super Server |
