SYS-R182-Z90 (rev. A00) - 1U - Server
- Order number: SYS-R182-Z90-A00
sysGen/GIGABYTE Server SYS-R182-Z90 (rev. A00), Mainboard MZ92-FS0... more
Product information "SYS-R182-Z90 (rev. A00) - 1U - Server"
sysGen/GIGABYTE Server SYS-R182-Z90 (rev. A00), Mainboard MZ92-FS0
Applications
- DB Processing
- Cloud Computing
- Data Center Appilcations
Features
- Dual Socket AMD EPYC™ 7003 series processor
- 8-Channel RDIMM/LRDIMM DDR4 per processor, 32 x DIMMs
- 4 x 3.5"/2.5" SATA hot-swappable HDD/SSD bays
- Ultra-Fast M.2 with PCIe Gen3 x4 interface
- 2 x PCIe x16 slot (Gen4 x16), FHHL
- 1 x OCP 3.0 Gen4 x16 mezzanine slot
- 1 x OCP 2.0 Gen3 x8 mezzanine slot
- 1x M.2 slots, M-key, PCIe Gen3 x4, supports NGFF.2242/2260/2280/22110
- Aspeed® AST2500 remote management controller
- 2 x 1Gb/s LAN ports (Intel® I350-AM2), 1 x dedicated management port
- 1200W (240V) 80 PLUS Platinum redundant/hot-swap power supply
NOTE: SAS card is required for SAS devices support
CPU TDP is limited to 225W if using M.2 device
| Applications: | Cloud Computing, Data Center, Virtualization |
| Case Depth: | 28.74 (730mm) |
| CPU Socket: | Dual Socket |
| CPU Type: | AMD EPYC 7002 ROME (2.Gen), AMD EPYC 7003 MILAN (3.Gen) |
| DIMM Slots: | 32 DIMMs |
| Drive Bays Form Factor: | 2.5", 3.5", M.2 |
| SSDs/HDDs: | 4 |
| Form Factor: | 1U |
| Max. GPU Count: | N/A |
| On-board Network: | 1GbE |
| Number of Nodes per System: | 1 Node |
| PCIe Slots: | 2 PCIe Slots |
| Redundant Power Supply: | Redundant Power Supply incl. |
| Remote Management: | Remote Management incl. |
| Storage Interface: | SAS (optional), SATA (native) |
| System Type: | Super Server |
