SYS-1114S-WN10RT - 1U - Server Barebone

Price On Request
Content: 1 Stück

Prices plus VAT plus shipping costs

Delivery time 4 Weeks

Configure

  • SYS-1114S-WN10RT
sysGen/SUPERMICRO Server SYS-1114S-WN10RT, Mainboard  Super H12SSW-NTR... more
Product information "SYS-1114S-WN10RT - 1U - Server Barebone"

sysGen/SUPERMICRO Server SYS-1114S-WN10RT, Mainboard Super H12SSW-NTR

Complete System Only:  To maintain quality and integrity, this product is sold only as a completely-assembled system (with 1 CPU, minimum 8 DIMMs, 1 NVMe). Recommended configuration for best performance is at least 24 or 32 Cores per CPU.

Applications

  • Virtualization
  • Cloud Computing
  • All Flash Storage

Features

  • Single AMD EPYC™ 7003/7002 Series Processor
  • 16 DIMMs; up to 4TB 3DS ECC DDR4-3200MHz RDIMM/LRDIMM
  • 2 PCI-E 4.0 x16 (FHHL) slots, 1 PCI-E 4.0 x16 (LP) slot
  • Integrated IPMI 2.0 + KVM with  dedicated LAN • Software Out of Band License key(SFT-OOB-LIC) included for OOB BIOS management
  • 10 Hot-swap U.2 NVMe4/NVMe3/SATA3 drive bays, fully hybrid drive support
  • 2x 10GBase-T LAN ports via Broadcom BCM57416 Controller
  • 1 VGA, 7 USB 3.0 (4 rear, 2 front, 1 Type A)
  • 2 SuperDOM (Disk on Module) ports
  • 750W Redundant Power Supplies Platinum Level High-efficiency
Applications: Cloud Computing, Virtualization
Case Depth: 23.5" (597mm)
CPU Socket: Single Socket
CPU Type: AMD EPYC 7002 ROME (2.Gen), AMD EPYC 7003 MILAN (3.Gen)
DIMM Slots: 16 DIMMs
Drive Bays Form Factor: 2.5", M.2
SSDs/HDDs: 10
Form Factor: 1U
Max. GPU Count: N/A
On-board Network: 10GBase-T
Number of Nodes per System: 1 Node
PCIe Slots: 3 PCIe Slots
Redundant Power Supply: Redundant Power Supply incl.
Remote Management: Remote Management incl.
Special Features: Complete System Only
Storage Interface: NVMe (native), SATA (native)
System Type: Super Server
Properties: "SYS-1114S-WN10RT - 1U - Server Barebone"
Applications: Cloud Computing, Virtualization
Case Depth: 23.5" (597mm)
CPU Socket: Single Socket
CPU Type: AMD EPYC 7002 ROME (2.Gen), AMD EPYC 7003 MILAN (3.Gen)
DIMM Slots: 16 DIMMs
Drive Bays Form Factor: 2.5", M.2
SSDs/HDDs: 10
Form Factor: 1U
Max. GPU Count: N/A
On-board Network: 10GBase-T
Number of Nodes per System: 1 Node
PCIe Slots: 3 PCIe Slots
Redundant Power Supply: Redundant Power Supply incl.
Remote Management: Remote Management incl.
Special Features: Complete System Only
Storage Interface: NVMe (native), SATA (native)
System Type: Super Server
