SYS-S452-Z30 (Rev. A00) - 4U - Storage Server

3,296.72€ *
Content: 1 Stück

Prices plus VAT plus shipping costs

Delivery time 3-4 Weeks

Configure

  • SYS-S452-Z30-A00
sysGen/Gigabyte Server SYS-S452-Z30 (rev. A00), Mainboard  MZ32-AR0... more
Product information "SYS-S452-Z30 (Rev. A00) - 4U - Storage Server"

sysGen/Gigabyte Server SYS-S452-Z30 (rev. A00), Mainboard MZ32-AR0

Applications

  • DB Processing
  • File Storage
  • Cloud Computing
  • Data Center Appilcations
  • Virtual Server

Features

  • Single AMD EPYC™ 7002/7003 series processor family
  • 16x DIMM slots up to 4TB 3DS ECC RDIMM/LRDIMM DDR4-3200MHz
  • 36 x 3.5" SATA/SAS hot-swap HDD/ SSD bays
    2 x 2.5" SATA hot-swap SSD bays
    4 x 2.5" SATA/NVMe hybrid hot-swap SSD bays
    NOTE: SAS card is required for SAS devices support
  • 2 x Ultra-Fast M.2 with PCIe Gen3 x4 bandwidth interface 2242/2260/2280
  • Up to 4 x PCIe Gen4 slots and 2 x PCIe Gen3 low profile slots
  • 2 x 1Gb/s LAN ports (Intel® I350-AM2), 1 x dedicated management port
  • Dual 1200W (240V) 80 PLUS Platinum redundant power supply
Applications: Backup Storage, Data Center
System Type: Storage Server
Form Factor: 4U
CPU Socket: Single Socket
CPU Type: AMD EPYC 7002 ROME (2.Gen), AMD EPYC 7003 MILAN (3.Gen)
Max. GPU Count: N/A
DIMM Slots: 16 DIMMs
Storage Interface: NVMe (native), SAS (optional), SATA (native)
Network Speed: 1GbE
Drive Bays: 42 Drives
Drive Bays Form Factor: 2.5", 3.5", M.2
PCIe Slots: 6 PCIe Slots
Case Depth: 24.6" (625mm)
Number of Nodes per System: 1 Node
Redundant Power Supply: Redundant Power Supply incl.
Remote Management: Remote Management incl.
Properties: "SYS-S452-Z30 (Rev. A00) - 4U - Storage Server"
Applications: Backup Storage, Data Center
System Type: Storage Server
Form Factor: 4U
CPU Socket: Single Socket
CPU Type: AMD EPYC 7002 ROME (2.Gen), AMD EPYC 7003 MILAN (3.Gen)
Max. GPU Count: N/A
DIMM Slots: 16 DIMMs
Storage Interface: NVMe (native), SAS (optional), SATA (native)
Network Speed: 1GbE
Drive Bays: 42 Drives
Drive Bays Form Factor: 2.5", 3.5", M.2
PCIe Slots: 6 PCIe Slots
Case Depth: 24.6" (625mm)
Number of Nodes per System: 1 Node
Redundant Power Supply: Redundant Power Supply incl.
Remote Management: Remote Management incl.
