NVIDIA JETSON ORIN NANO 8GB DEVELOPMENT KIT

The NVIDIA Jetson Orin Nano Developer Kit sets a new standard for creating entry-level AI-powered robots, smart drones, and intelligent cameras, and simplifies getting started with the Jetson Orin Nano series. Compact design, lots of connectors and up to 40 TOPS of AI performance make this developer kit perfect for transforming your visionary concepts into reality. With up to 80X the performance of Jetson Nano, it can run all modern AI models, including transformer and advanced robotics models.

The developer kit comprises a Jetson Orin Nano 8GB module and a reference carrier board that can accommodate all Orin Nano and Orin NX modules, providing an ideal platform for prototyping your next-gen edge AI product. The Jetson Orin Nano 8GB module features an Ampere GPU and a 6-core ARM CPU, enabling multiple concurrent AI application pipelines and high-performance inference. The carrier board boasts a wide array of connectors, including two MIPI CSI connectors supporting camera modules with up to 4-lanes, allowing higher resolution and frame rate than before.

Jetson runs the NVIDIA AI software stack, with available use-case-specific application frameworks, including NVIDIA Isaac for robotics, DeepStream for vision AI, and Riva for conversational AI. You can save significant time with NVIDIA Omniverse Replicator for synthetic data generation (SDG), and with NVIDIA TAO Toolkit for fine-tuning pretrained AI models from the NGCTM catalog.

Ecosystem partners offer additional AI and system software, developer tools, and custom software development. They can also help with cameras and other sensors, as well as carrier boards and design services for your product.

Jetson Orin modules are unmatched in performance and efficiency for robots and other autonomous machines, and give you the flexibility to create the next generation of AI solutions with the latest NVIDIA technology. Together with the world-standard NVIDIA AI software stack and an ecosystem of services and products, your road to market has never been faster.

Developer Kit Content (P3766)

• Jetson Orin Nano 8GB module with heat sink and reference carrier board
• DC Power Supply
• 802.11ac/abgn wireless network interface controller
• Quick Start Guide

Jetson Orin Nano 8GB Module

• NVIDIA Ampere architecture with 1024 NVIDIA CUDA cores with 32 tensor cores
• 6-core Arm Cortex-A78AE v8.2 64-bit CPU
• 8GB 128-bit LPDDR5 68 GB/s
• Supports for external NVMe

Reference carrier board

• 2x MIPI CSI-2 22-pin camera connectors
• 2x M.2 Key M, M.2 Key E
• 4x USB 3.2 Gen2 Type-A
• USB Type-C for UFP
• Gigabit Ethernet
• DisplayPort
• microSD slot
• 40-pin expansion header
• DC power jack
