SYS-740A-T - MID TOWER
- Order number: SYS-740A-T
sysGen/SUPERMICRO SYS-740A-T , includes: Mainboard Super X12DAI-N6 / Mid... more
Product information "SYS-740A-T - MID TOWER"
sysGen/SUPERMICRO SYS-740A-T, includes:
Mainboard Super X12DAI-N6 / Mid Tower CSE-745BTS-R1K23BP3
- Entry-Level Workstation
- Designed for CAD and 3D Modeling Applications
- Engineering/scientific research
- Dual Socket P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable processor support
- 16 DIMM slots 3200MHz ECC DDR4 RDIMM, LRDIMM
Up to 4TB: 16x 256 GB DRAM
Up to 6TB: 8x 256 GB DRAM and 8x 512 GB PMem
Intel® Optane™ persistent memory 200 series - 5 PCI-E 4.0 x16, 1 PCI-E 4.0 x8, 2 NVMe M.2 slots
- 8x 3.5" hot-swap SATA (SAS/NVMe optional) drive bays (4x 2.5" NVMe hybrid)
3x 5.25" drive bays (optional) - Dual 1200W Titanium level power supplies for high powered configurations
| Applications: | CAD, CAM, General Purpose |
| Case Depth: | 25.5" (648mm) |
| CPU Socket: | Dual Socket |
| CPU Type: | Intel Xeon Scalable Ice Lake (3.Gen) |
| DIMM Slots: | 16 DIMMs |
| Drive Bays Form Factor: | 3.5", 5.25, M.2 |
| SSDs/HDDs: | 8 Drives |
| Form Factor: | Mid-Tower |
| Max. GPU Count: | 2 GPUs |
| On-board Network: | 1GbE |
| PCIe Slots: | 6 PCIe Slots |
| Redundant Power Supply: | Redundant Power Supply incl. |
| Remote Management: | Remote Management incl. |
| Storage Interface: | NVMe (optional), SAS (optional), SATA (native) |
| System Type: | Workstation |
Related links to "SYS-740A-T - MID TOWER"
Properties: "SYS-740A-T - MID TOWER"
| Applications: | CAD, CAM, General Purpose |
| Case Depth: | 25.5" (648mm) |
| CPU Socket: | Dual Socket |
| CPU Type: | Intel Xeon Scalable Ice Lake (3.Gen) |
| DIMM Slots: | 16 DIMMs |
| Drive Bays Form Factor: | 3.5", 5.25, M.2 |
| SSDs/HDDs: | 8 Drives |
| Form Factor: | Mid-Tower |
| Max. GPU Count: | 2 GPUs |
| On-board Network: | 1GbE |
| PCIe Slots: | 6 PCIe Slots |
| Redundant Power Supply: | Redundant Power Supply incl. |
| Remote Management: | Remote Management incl. |
| Storage Interface: | NVMe (optional), SAS (optional), SATA (native) |
| System Type: | Workstation |
