NVIDIA JETSON ORIN NX 16GB

Preis auf Anfrage
Inhalt: 1 Stück

zzgl. MwSt. zzgl. Versandkosten




  • NVIDIA JETSON ORIN NX 16GB - 900-13767-0000-000
The NVIDIA Jetson Orin NX 16GB module delivers up to 100 TOPS of AI performance in the... mehr
Produktinformationen "NVIDIA JETSON ORIN NX 16GB"

The NVIDIA Jetson Orin NX 16GB module delivers up to 100 TOPS of AI performance in the smallest Jetson form-factor, with power configurable between 10W and 25W. This gives you 3X the performance of NVIDIA Jetson AGX Xavier and 5X the performance of NVIDIA Jetson Xavier NX, making it ideal for small form-factor, low-power products like drones and handheld devices.



This system-on-module supports multiple concurrent AI application pipelines with the NVIDIA Ampere GPU architecture, next-generation deep learning and vision
accelerators, high-speed IO, and fast memory bandwidth. Now you can develop solutions using your largest and most complex AI models to solve problems such as natural language understanding, 3D perception, and multi-sensor fusion.



Jetson runs the NVIDIA AI software stack, and use-case specific application frameworks are available, including Isaac for robotics, DeepStream for vision AI, and Riva for conversational AI. You can save significant time with NVIDIA Omniverse Replicator for synthetic data generation (SDG), and by using NVIDIA TAO toolkit to fine-tune pretrained AI models from the NGC catalog.



Jetson ecosystem partners offer additional AI and system software, developer tools, and custom software development. They can also help with cameras and other sensors, as well as carrier boards and design services for your product. Jetson Orin modules are unmatched in performance and efficiency for robots and other autonomous machines, and they give you the flexibility to create the next generation of AI solutions with the latest NVIDIA GPU technology. Together with the world-standard NVIDIA AI software stack and an ecosystem of services and products, your road to market has never been faster.



Features:

  • 1024-core NVIDIA Ampere architecture
  • GPU with 32 Tensor Cores
  • 2x NVDLA v2.0
  • 8-core Arm Cortex-A78AE v8.2 64-bit CPU
  • 16GB 128-bit LPDDR5
  • PVA v2.0

Power

  • Voltage input 5V-20V
  • Module Power: 10W-25W
CPU: 8-core NVIDIA Arm Cortex | A78AE v8.2 64-bit CPU | 2MB L2 + 4MB L3
Speicher: 6GB 128-bit LPDDR5 102.4 GB/s
Datenspeicher: Supports external NVMe via PCIe
GPU: NVIDIA Ampere architecture | 1024 NVIDIA CUDA cores | 32 Tensor cores
Sehbeschleuniger: PVA v2.0
DL Beschleuniger: 2x NVDLA v2.0
Power: 10W-25W
Abmessung: 45 mm x 69.6 mm | 260 pin SO-DIMM connector
Eigenschaften: "NVIDIA JETSON ORIN NX 16GB"
CPU: 8-core NVIDIA Arm Cortex | A78AE v8.2 64-bit CPU | 2MB L2 + 4MB L3
Speicher: 6GB 128-bit LPDDR5 102.4 GB/s
Datenspeicher: Supports external NVMe via PCIe
GPU: NVIDIA Ampere architecture | 1024 NVIDIA CUDA cores | 32 Tensor cores
Sehbeschleuniger: PVA v2.0
DL Beschleuniger: 2x NVDLA v2.0
Power: 10W-25W
Abmessung: 45 mm x 69.6 mm | 260 pin SO-DIMM connector
